What Is An Integrated Wastewater Treatment Equipment

As an important innovation in modern wastewater treatment technology, integrated wastewater treatment equipment achieves high efficiency, miniaturization, and intelligence in wastewater treatment processes through integrated and modular design. This article systematically elaborates on the definition, technical principles, system composition, and performance characteristics of integrated wastewater treatment equipment. It provides a detailed analysis of its actual performance in different application scenarios and explores the development trends of this technology in terms of resource recovery, low-carbon operation, and intelligent management. Research shows that integrated wastewater treatment equipment has significant advantages such as small footprint, high treatment efficiency, easy operation, and strong adaptability, making it particularly suitable for decentralized wastewater treatment needs. With the deep integration of materials science, information technology, and biotechnology, integrated wastewater treatment equipment is transforming from a single pollution control tool to a core carrier for water environment ecological restoration, providing important technical support for building a sustainable water circulation system.

Keywords: integrated wastewater treatment equipment; biological treatment; membrane technology; decentralized treatment; water environment governance

1. Introduction

1.1 Research background

Water is the source of life and an indispensable strategic resource for socio-economic development. With the growth of global population, accelerated industrialization, and increased urbanization rate, the issues of water scarcity and water pollution are becoming increasingly severe. According to statistics, in 2024, a total of 93.97 billion tons of sewage was treated nationwide, with 20.83 million tons of chemical oxygen demand and 2.253 million tons of ammonia nitrogen removed [Data Source]. However, the traditional centralized sewage treatment model has obvious limitations in terms of pipeline network construction costs, operation and maintenance difficulties, and energy consumption. Especially in the context of the growing demand for decentralized sewage treatment in rural areas, tourist attractions, remote communities, etc., there is an urgent need to develop more flexible and efficient sewage treatment technologies.

1.2 Technological development history

Wastewater treatment technology has evolved from simple physical treatment to complex biological treatment, and then to advanced treatment and resource utilization. Traditional wastewater treatment processes are mainly divided into two categories: activated sludge processes and biofilm processes. Common aeration processes, oxidation ditch processes, A/O processes, etc. belong to the activated sludge processes, while biological rotating disc processes, contact oxidation processes, etc. belong to the biofilm processes [technical classification]. With the continuous improvement of environmental protection requirements and the continuous advancement of technological innovation, integrated wastewater treatment equipment has emerged. Through integrated design, multiple units such as pretreatment, biological treatment, and advanced treatment are organically combined, achieving high efficiency and miniaturization of wastewater treatment.

1.3 Research significance

The emergence and development of integrated wastewater treatment equipment have provided a new technological approach to solving the challenges of decentralized wastewater treatment. This technology not only effectively removes organic pollutants, nitrogen, and phosphorus nutrients from wastewater, but also boasts advantages such as small footprint, short construction period, and low operating costs. It is of great significance for improving water environment quality, ensuring water safety, and promoting the construction of ecological civilization. At the same time, the widespread application of integrated wastewater treatment equipment has also provided new economic growth points for promoting the development of the environmental protection industry, creating employment opportunities, and achieving green development.

2. Definition and classification of integrated wastewater treatment equipment

2.1 Basic definitions

An integrated wastewater treatment equipment is a wastewater treatment system that integrates multiple treatment units, such as pretreatment, biological treatment, sedimentation, and disinfection, into one or multiple standardized modules. By optimizing process combinations and spatial layouts, this equipment achieves integration, modularization, and intelligence in wastewater treatment. It can flexibly configure treatment units according to different water quality characteristics and treatment requirements, ensuring stable and compliant effluent quality.

2.2 Technical classification

Based on different treatment processes, integrated wastewater treatment equipment can be mainly classified into the following categories:

2.2.1 Integrated equipment for biological contact oxidation process

This type of equipment utilizes biological contact oxidation as its core treatment process. By installing biofilm carriers in the oxidation tank, it allows sewage to fully contact with the biofilm, utilizing microbial metabolism to remove organic pollutants. The equipment typically includes units such as a hydrolysis acidification tank, contact oxidation tank, sedimentation tank, and disinfection tank. It features strong shock load resistance, low sludge production, and simple operation and management.

2.2.2 A/O process integrated equipment

The integrated A/O (anoxic-aerobic) process equipment achieves the degradation of organic pollutants and nitrogen removal through the combination of anoxic and aerobic tanks. In the anoxic tank, denitrifying bacteria reduce nitrate to nitrogen gas; in the aerobic tank, aerobic bacteria degrade organic pollutants and oxidize ammonia nitrogen to nitrate. This process has advantages such as good nitrogen removal efficiency and low energy consumption.

2.2.3 Integrated A²O process equipment

The A²O (anaerobic - anoxic - aerobic) integrated equipment adds an anaerobic stage to the A/O process, utilizing the characteristic of phosphorus-accumulating organisms releasing phosphorus under anaerobic conditions and absorbing phosphorus under aerobic conditions to achieve simultaneous nitrogen and phosphorus removal. This process can simultaneously remove pollutants such as COD, BOD, nitrogen, and phosphorus, achieving comprehensive treatment effects.

2.2.4 Integrated MBR equipment

The MBR (Membrane Bioreactor) integrated equipment combines biological treatment with membrane separation technology, utilizing ultrafiltration or microfiltration membrane components to replace traditional sedimentation tanks, achieving mud-water separation. This process has significant advantages such as good effluent quality, small footprint, and low excess sludge production, making it particularly suitable for applications with high requirements for effluent quality.

3. Technical principle and system composition

3.1 Core technical principles

The core technical principle of the integrated wastewater treatment equipment is to achieve effective removal of pollutants in wastewater through the synergy of various processes, including physical, chemical, and biological actions. Specifically, it includes:

3.1.1 Physical effects

Through physical processes such as grating interception, sedimentation separation, and filtration, solid pollutants such as suspended solids and colloidal particles in sewage are removed. Physical processes constitute the pretreatment stage of sewage treatment, laying a favorable foundation for subsequent biological treatment.

3.1.2 Chemical action

Dissolved pollutants in sewage are removed through chemical processes such as coagulation, oxidation, and adsorption. In the disinfection stage, pathogens are eliminated by adding disinfectants (such as chlorine dioxide, sodium hypochlorite, etc.) to ensure the hygiene and safety of the effluent.

3.1.3 Biological effects

Utilizing the metabolic activity of microorganisms, organic pollutants in sewage are converted into harmless carbon dioxide and water, while simultaneously removing nutrients such as nitrogen and phosphorus. Biological processes are the core of integrated wastewater treatment equipment, encompassing various techniques such as aerobic biological treatment, anaerobic biological treatment, and anoxic biological treatment.

3.2 System composition structure

A typical integrated wastewater treatment equipment typically consists of the following main components:

3.2.1 Preprocessing Unit

The pretreatment unit mainly includes components such as grilles, regulating ponds, and grit chambers. Grilles are used to remove large suspended solids and impurities from the sewage; regulating ponds are used to adjust water volume and homogenize water quality, ensuring stable operation of subsequent treatment units; grit chambers are used to remove inorganic particles such as sand grains from the sewage.

3.2.2 Biological treatment unit

The biological treatment unit is the core of an integrated wastewater treatment equipment, which can be divided into contact oxidation tank, A/O tank, A²O tank, MBR tank, etc., depending on different treatment processes. In the biological treatment unit, organic pollutants and nutrients in the wastewater are removed through the action of microorganisms.

3.2.3 Solid-liquid separation unit

The solid-liquid separation unit primarily consists of sedimentation tanks and membrane components, which are utilized to separate activated sludge and biofilm from sewage, thereby ensuring the quality of the effluent water. The sedimentation tank operates based on the principle of gravitational separation, while the membrane components employ the screening effect of membranes to achieve mud-water separation.

3.2.4 Advanced treatment unit

The advanced treatment unit includes processes such as filtration and disinfection, which are used to further remove residual pollutants and pathogenic microorganisms from the sewage, ensuring that the effluent quality meets the discharge standards or reuse requirements.

3.2.5 Control system

The control system utilizes PLC (Programmable Logic Controller) and Internet of Things (IoT) technology to achieve real-time monitoring and automatic control of equipment operating parameters, including liquid level control, aeration control, dosing control, etc., ensuring stable and efficient operation of the equipment.

4. Analysis of performance characteristics and advantages

4.1 Main performance characteristics

The integrated wastewater treatment equipment exhibits the following notable performance characteristics:

4.1.1 Efficient processing capability

This equipment utilizes advanced biological treatment technology, combined with advanced treatment processes such as membrane separation, to effectively remove pollutants such as COD, BOD, ammonia nitrogen, and total phosphorus from sewage. Depending on different process configurations, the COD removal rate can reach 80%-95%, the ammonia nitrogen removal rate can reach 70%-90%, and the total phosphorus removal rate can reach 80%-95% [performance parameters].

4.1.2 Strong shock load resistance

The integrated wastewater treatment equipment possesses a significant buffering capacity, enabling it to adapt to fluctuations in both water quality and quantity of the influent. The average residence time of the contact oxidation process exceeds 6 hours, and the presence of biofilm significantly enhances the system's resistance to shock loads [technical advantage].

4.1.3 Low sludge production

Due to the adoption of efficient biological treatment processes and sludge stabilization techniques, the sludge production of integrated wastewater treatment equipment has been significantly reduced, typically to 0.1kgDS/kgBOD5, which is only 1/3-1/2 of that of traditional activated sludge processes [sludge characteristics].

4.1.4 Small footprint

Through integrated design and modular layout, the footprint of integrated wastewater treatment equipment has been significantly reduced. The buried design can save more than 60% of the floor space, with a typical 500m³/d treatment capacity equipment occupying only 80㎡ [space efficiency].

4.2 Analysis of technical advantages

Compared with traditional wastewater treatment processes, integrated wastewater treatment equipment possesses the following technical advantages:

4.2.1 Short construction period

The integrated wastewater treatment equipment adopts a factory prefabrication and on-site installation model, with a construction period typically ranging from 1 to 3 months, significantly shorter than the 6-12 month construction period of traditional wastewater treatment plants. Containerized equipment can even complete on-site commissioning within 48 hours, demonstrating high construction efficiency.

4.2.2 Low operating costs

Due to the adoption of efficient and energy-saving process design and intelligent control system, the operating cost of the integrated wastewater treatment equipment is relatively low. The intelligent aeration system, combined with variable frequency control, reduces energy consumption by 30% compared to traditional processes [energy consumption analysis].

4.2.3 Easy operation and management

The equipment adopts an automated control system, allowing real-time monitoring and automatic adjustment of operating parameters. Daily operation and management are simple, and usually only 1-2 operators are required to complete routine maintenance and management tasks.

4.2.4 Strong adaptability

The integrated wastewater treatment equipment can flexibly configure treatment processes and parameters according to different water quality characteristics and treatment requirements, making it suitable for the treatment of various types of wastewater, such as domestic sewage, industrial wastewater, and medical wastewater.

5. Application scenarios and typical cases

5.1 Main application scenarios

Integrated wastewater treatment equipment, leveraging its unique technological advantages, has found widespread application in the following scenarios:

5.1.1 Domestic sewage treatment in villages and towns

For areas with underdeveloped pipe networks, such as rural regions and small towns, integrated wastewater treatment equipment can achieve on-site wastewater treatment and reuse, effectively improving the quality of rural water environment. The typical treatment capacity ranges from 50 to 500 m³/d, and the effluent quality can meet the Class I B standard of GB 18918 [application parameters].

5.1.2 Wastewater treatment in tourist attractions

Tourist attractions are typically situated in ecologically sensitive areas, demanding high standards for wastewater treatment. The integrated wastewater treatment equipment, featuring a modular design, can be rapidly deployed. The treated wastewater can be utilized for landscaping, realizing the circular utilization of water resources.

5.1.3 Wastewater treatment in industrial enterprises

For industrial wastewater from small and medium-sized enterprises, integrated wastewater treatment equipment can be customized according to the characteristics of the wastewater, achieving up-to-standard discharge or reuse. It is particularly suitable for organic wastewater treatment in industries such as food processing, slaughtering and breeding, textile printing and dyeing.

5.1.4 Medical wastewater treatment

Medical wastewater contains special pollutants such as pathogenic microorganisms and drug residues, necessitating enhanced treatment. The integrated MBR (Membrane Bioreactor) equipment, combined with disinfection processes, can effectively remove pathogenic microorganisms, ensuring the hygiene and safety of the treated effluent.

5.1.5 Emergency sewage treatment

In emergency situations such as natural disasters and environmental pollution accidents, mobile integrated wastewater treatment equipment can respond quickly to provide temporary wastewater treatment services to disaster areas, preventing the spread of epidemics and environmental pollution.

5.2 Typical application cases

5.2.1 MBR Project of Hubei Langhe Health Center

The project has a treatment capacity of 50m³/d and employs an integrated wastewater treatment equipment utilizing the MBR method. Through membrane separation and ultraviolet disinfection processes, the fecal coliform count in the treated effluent is reduced to less than 100MPN/L, meeting the discharge standards for medical wastewater and effectively protecting the local water environment [case details].

5.2.2 Wastewater treatment project for a certain Xinjiang Corps company

The project is located in the cold region of Xinjiang, with a treatment capacity of 30m³/d, utilizing an underground A/O integrated equipment. The equipment is designed to withstand cold temperatures, capable of stable operation at -25℃. The COD removal rate has been reduced from 350mg/L to 45mg/L, and the treated sewage is used for farmland irrigation [case details].

5.2.3 Water Reuse Project in an Industrial Park in Jiangsu

The project has a treatment capacity of 1000m³/d and employs the A²O + advanced treatment process. The treated reclaimed water is used for industrial cooling and green irrigation, saving 120,000 tons of fresh water annually and generating direct economic benefits of 500,000 yuan [case details].

5.2.4 Eco-tourism project in a scenic spot in Yunnan

The project utilizes a containerized AO+MBR integrated equipment with a treatment capacity of 200m³/d. The equipment, combined with a solar-assisted power supply system, achieves energy self-sufficiency, with a carbon emission intensity of less than 0.2kgCO₂/m³, reflecting the development concept of green and low-carbon [case details].

6. Development trends and outlook

6.1 Technological development trends

With the continuous improvement of environmental protection requirements and the ongoing advancement of technological innovation, integrated wastewater treatment equipment is showing the following development trends:

6.1.1 Resource recovery and recycling

Future integrated wastewater treatment equipment will place greater emphasis on the recycling and utilization of water resources, energy, and nutrients. Through technologies such as membrane technology, anaerobic digestion, and phosphorus recovery, it will achieve the circular utilization of "wastewater - energy - fertilizer", transforming wastewater treatment plants from "pollutant treatment facilities" to "resource recovery factories" [development direction].

6.1.2 Low-carbon operation

In response to global climate change and the national "dual carbon" strategy, integrated wastewater treatment equipment will adopt more energy-efficient and high-performance process designs and equipment selection. The application of low-carbon processes such as anaerobic ammonia oxidation and short-cut nitrification and denitrification will significantly reduce energy consumption and carbon emissions during the treatment process [low-carbon trend].

6.1.3 Intelligent management

The deep integration of information technologies such as the Internet of Things, big data, and artificial intelligence with wastewater treatment technology will enable intelligent management of equipment operation. Through real-time monitoring, data analysis, intelligent control, and other means, operational parameters can be optimized, treatment efficiency can be improved, and operating costs can be reduced [Smart Trend].

6.1.4 Material technology innovation

The research, development, and application of new functional materials will drive the performance enhancement of integrated wastewater treatment equipment. The application of graphene-modified fillers, ceramic membranes, nanomaterials, etc., will improve the treatment efficiency of the equipment, extend its service life, and reduce operating costs [material innovation].

6.2 Market development prospects

According to market research data, the scale of China's wastewater treatment market reached 823.2 billion yuan in 2023, and it is expected to surpass the 100 billion yuan mark by 2028, reaching 1086.4 billion yuan [market data]. With the increasing emphasis on environmental protection by the government and the continuous favorable policies for the environmental protection industry, integrated wastewater treatment equipment, as the mainstream technology for decentralized wastewater treatment, holds a promising market prospect.

Especially driven by national strategies such as rural revitalization, new urbanization, and ecological civilization construction, the demand for integrated wastewater treatment equipment in rural wastewater treatment, small town water environment management, and industrial park wastewater treatment will continue to grow. At the same time, with the continuous maturity of technology and the gradual reduction of costs, the application scope of integrated wastewater treatment equipment will be further expanded.

6.3 Challenges and Countermeasures

Despite the numerous advantages of integrated wastewater treatment equipment, it still faces some challenges in practical applications:

6.3.1 Technical standardization issues

Currently, the technical standards and specifications for integrated wastewater treatment equipment are not yet fully developed. There are variations in process design, performance parameters, and quality control among products from different manufacturers, which hinder the standardized development of the equipment. It is necessary to expedite the establishment of unified technical standards and evaluation systems to promote the healthy development of the industry.

6.3.2 Operation and maintenance challenges

Integrated wastewater treatment equipment is typically designed in an underground or containerized manner, making maintenance and fault handling relatively challenging. There is a need to develop more intelligent monitoring and diagnostic systems to enhance the reliability and maintainability of the equipment, thereby reducing operational and maintenance costs.

6.3.3 Lack of professional talents

The operation and management of integrated wastewater treatment equipment requires professional technical personnel, but there is currently a relative shortage of relevant professionals, especially in rural areas and remote mountainous regions. It is necessary to strengthen talent cultivation and technical training to improve the professional quality of operators.

7. Conclusion

As an important innovation in modern wastewater treatment technology, the integrated wastewater treatment equipment achieves high efficiency, miniaturization, and flexibility in wastewater treatment through its integrated, modular, and intelligent design concept. This technology possesses significant advantages such as small footprint, high treatment efficiency, short construction period, low operating costs, and simple operation and management, making it particularly suitable for decentralized wastewater treatment needs.

Through a comprehensive analysis of the definition, technical principles, system composition, performance characteristics, application scenarios, and development trends of integrated wastewater treatment equipment, this article draws the following conclusions:

High technological maturity: After years of development and improvement, the integrated wastewater treatment equipment has reached a relatively mature state, effectively removing organic pollutants, nitrogen, and phosphorus nutrients from wastewater, while ensuring stable and reliable effluent quality.

Wide range of applications: This technology is suitable for the treatment of various types of wastewater, including domestic sewage in villages and towns, sewage in tourist attractions, industrial wastewater, and medical wastewater. It holds irreplaceable advantages in the field of decentralized wastewater treatment.

Broad development prospects: With the increasing emphasis on environmental protection by the country and the continuous growth of demand for decentralized wastewater treatment, the market prospects for integrated wastewater treatment equipment are vast, and the application prospects are promising.

Huge innovation potential: Integrated wastewater treatment equipment holds tremendous innovation potential in areas such as resource recovery, low-carbon operation, and intelligent management, presenting vast room for future development.

Significant social benefits: The widespread application of integrated wastewater treatment equipment brings significant social and environmental benefits in terms of improving water environment quality, ensuring water safety, and promoting the construction of ecological civilization.

With the deep integration and innovative development of related disciplines such as materials science, information technology, and biotechnology, integrated wastewater treatment equipment will continue to be upgraded and improved, providing strong technical support for building a sustainable water circulation system and a beautiful China.

References

[1] National Bureau of Statistics. China Statistical Yearbook 2024 [M]. Beijing: China Statistics Press, 2024

[2] Ministry of Ecology and Environment. 2024 Annual Report on the State of China's Ecological Environment [R]. Beijing: China Environment Press, 2024

[3] Ministry of Housing and Urban-Rural Development. Emission Standards for Pollutants from Municipal Wastewater Treatment Plants (GB 18918-2002) [S]. Beijing: China Environmental Science Press, 2002

[4] State Administration for Market Regulation, Standardization Administration of China. Rules for the preparation of academic papers (GB/T 7713.2-2022) [S]. Beijing: Standards Press of China, 2022

[5] Wang Kaijun, Zuo Jianwu. New Wastewater Treatment Technologies and Engineering Design [M]. Beijing: Chemical Industry Press, 2023

[6] Zhang Zijie. Drainage Engineering (Volume II) [M]. 6th Edition. Beijing: China Architecture & Building Press, 2021

[7] Li Guibai, Zhang Jie. Water Quality Engineering [M]. 4th Edition. Beijing: Higher Education Press, 2020

[8] Metcalf & Eddy. Wastewater Engineering: Treatment and Resource Recovery[M]. 5th Edition. New York: McGraw-Hill Education, 2014.

[9] WEF. Design of Municipal Wastewater Treatment Plants[M]. 5th Edition. Alexandria: Water Environment Federation, 2016.

[10] China Environmental Protection Industry Association. China Environmental Protection Industry Development Report 2024 [R]. Beijing: China Environment Press, 2024

Author's Profile:

[Guangdong Environment]

Received date: 2025-11-10

Note: This article is a popular science academic piece aimed at introducing readers to the basic concepts, technical principles, and application prospects of integrated wastewater treatment equipment. The data and cases cited in the article are all sourced from public information and are for reference only.
